Description
Basic coated, low hydrogen electrode for producing tough and crack-free welded joints. Good operating characteristics while performing positional welding. Best in class electrode for root joint welding.
USP'S :
- Ultra smooth finely rippled weld beads.
- Less than 4.0 ml diffusible hydrogen.
- Excellent impact notch toughness in class.
- Superior reliability for the critical welding of C-Mn microlloyed & low alloy structural steels.
TechnicaL Specification
| PRODUCT NAME | AWS/SFA | YIELD STRENGTH N/MM2 | TENSILE STRENGTH N/MM2 | ELONGATION A5(%) | CHARPY IMPACT VALUE ISO-V J+0°C | PRODUCT NAME | AWS/SFA | YIELD STRENGTH N/MM2 | TENSILE STRENGTH N/MM2 | ELONGATION A5(%) | CHARPY IMPACT VALUE ISO-V J+0°C | PRODUCT NAME | AWS/SFA | YIELD STRENGTH N/MM2 | TENSILE STRENGTH N/MM2 | ELONGATION A5(%) | CHARPY IMPACT VALUE ISO-V J+0°C |
| SUPER OPTIMAL 7016 | E 7016 - H4 | 450 | 550-620 | 30 | 70 | SUPER OPTIMAL 7016 | E 7016 - H4 | 450 | 550-620 | 30 | 70 | SUPER OPTIMAL 7016 S | E 7016-1 H4 | 450 | 550-620 | 30 | 70 |
